Stick Module for DualSense Edge Wireless Controller

Step 1
Make sure the player indicator on the controller is off. If the player indicator is on, press and hold the PS button until it turns off.

Step 2
Disconnect the USB cable from the controller.

Step 3
Remove the front cover. Slide the RELEASE latch on the back of your controller to remove the cover.

Step 4
Raise the release lever.

Step 5
Remove the stick module and attach a new stick module. Make sure that the stick module is positioned correctly, and then slide the module along the grooves of the controller until you hear a click.

Step 6
Lower the release lever.

Step 7
Attach the front cover. Align the raised parts of the cover with the notches on the controller, and then carefully push the cover into place until you hear a click.
